Beam High-Precision Load Cell Scale Sensor 107 5 300 Kg 500kg 1000kg 1t 2t 5t 10t S Type High Accuracy Pressure Weight Sensor Load Cell for DIY Electronic(1500KG)

Specifications:Theory : Resistance SensorUsage : Pressure SensorMaterial : MetalType : Magnetic SensorOutput : Analog SensorOrigin : Mainland ChinaCapacity : 2~10000KGType : Load Cell/Force SensorOrigin : Mainland ChinaSensitivity : 2.0± 0.05mv/vNonlinear : ±0.05%FSlagging : ±0.05%FSRepeatability : ±0.03%FSCreep : ±0.05%FS/30minZero point output : ±1%FS/30minzero temperature : ±0.05%FS/30minSensitivity temperature coefficient : ±0.05%FS/30minWorking temperature range : -20°C~+80°CInput resistance : 350±20Output resistance : 350±5Safety overload : 150%FSInsulation resistance : >5000M(50VDC)Recommended excitation voltage : 5V-15V

• 1. High-Precision Measurement: Our Beam High-Precision Load Cell Scale Sensor ensures accurate and reliable measurements for a wide range of weights, ranging from 107kg to 10t. With its resistance sensor theory and magnetic sensor type, it guarantees precise readings with a sensitivity of 2.0± 0.05mv/v.
• 2. Crafted with metal material, this load cell sensor is built to withstand heavy-duty usage. Its robust design and Mainland China origin ensure long-lasting performance in various industrial applications.
• 3. Exceptional Performance: With a nonlinearity of ±0.05%FS and repeatability of ±0.03%FS, our load cell sensor delivers consistent and accurate results. The lagging and creep values of ±0.05%FS and ±0.05%FS/30min respectively further enhance its precision.
• 4. Versatile Temperature Range: Designed to operate in extreme conditions, our load cell sensor can withstand temperatures from -20°C to +80°C. Its zero temperature coefficient of ±0.05%FS/30min and working temperature range enable reliable measurements in any environment.
• 5. Enhanced Safety Features: Safety is paramount, and our load cell sensor prioritizes it. With a safety overload capacity of 150%FS and insulation resistance greater than 5000M(50VDC), it ensures secure operation even under demanding conditions. The recommended excitation voltage of 5V-15V ensures optimal performance while maintaining safety standards.
